FEATURE
- High Torque
- High Precision
- High Torsional Rigidity
- Long-Term Persistence of Low Backlash
- Long Service Life
- High Efficiency / Optimized Inertia Moment
- Identical Input-Output Rotating Direction with Hypoid Right-Angle K-Series
- Various Shaft or Flange Output Interfaces
OVERVIEW
Output torque
- AH Series T2N : 24 Nm - 10915 Nm
- AHK Series T2N : 24 Nm - 10980 Nm
Ratios
- AH Series : 4 ~ 100
- AHK Series : 12 ~ 10000
Low backlash
- AH Series : ≦1 arcmin ~ ≦3 arcmin
- AHK Series : ≦2 arcmin ( AHK064 ≦3 arcmin )
High efficiency
- AH Series : ≧ 97% / ≧ 94%
- AHK Series : ≧ 94% / ≧ 90%
SIZE
- AH064 ~ AH450
- AHK064 ~ AHK450
