FEATURE
- Enhanced Axial and Radial Load
- Enlarged Holes on Flange for Easy Installation and Adjustment
- High Torque
- High Torsional Rigidity
- High Precision
- Long-Term Persistence of Low Backlash
- Long Service Life
- High Efficiency / Optimized Inertia Moment
- Identical Input-Output Rotating Direction with Hypoid Right-Angle K-Series
OVERVIEW
Output torque
- MGO Series T2N : 55 Nm - 5780 Nm
- MGOK Series T2N : 55 Nm - 5905 Nm
Ratios
- MGO Series : 4 ~ 400
- MGOK Series : 4 ~ 10000
Low backlash
- MGO Series : ≦3 arcmin ~ ≦4 arcmin
- MGK Series : ≦4 arcmin
High efficiency
- MGO Series : ≧ 97% ~ ≧ 92%
- MGOK Series : ≧ 95% ~ ≧ 90%
SIZE
- MGO115 ~ MGO320
- MGOK115 ~ MGOK320
